• GS60E systems offer superior business and technical application performance with large I/O capacity to tackle the most demanding enterprise applications

GS60E systems include:

• Processor module with two Alpha 21264 6/525-MHz CPUs, each with 4-MB L2 cache or two Alpha 21264 6/700-MHz CPUs, each with 8-MB L2 cache
• System I/O module with four I/O channels
• 1-GB or 4-GB memory
• PCI Shelf Mount Box
• 10/100 Mb Fast Ethernet network interface card
• UltraSCSI 1-port Single-ended adapter
• UltraSCSI 16-bit StorageWorks shelf with power supply and 1-m SCSI cable
• 9.1-GB UltraSCSI disk drive
• 600-MB CD-ROM drive
• PCI SCSI controller and 2-m SCSI cable for connection to
  CD-ROM
• 3-phase power system with power cord
• Redundant 48 VDC hot swappable power supplies to power CPU, memory, I/O, and PCI shelves
• 120/240 Vac power for StorageWorks shelves
• Shielded console cable for connection to console terminal
• Tru64™ UNIX or OpenVMS Factory Installed Software
• 90-day software product warranty
• Protected by Compaq Services, including one-year, on-site, four-hour response warranty; system installation must be ordered separately

Processor
Two Alpha 21264 6/525 MHz processors (2 CPUs per module) with AlphaServer GS60E 6/525 systems
Two Alpha 21264 6/700 MHz processors (2 CPUs per module) with AlphaServer GS60E 6/700 systems

Cache Memory
4-MB ECC L2 onboard cache per 6/525 MHz CPU; 8-MB ECC L2 onboard cache per 6/700 MHz CPU

Architecture
64-bit bus-based system architecture with seven system bus slots for CPU, memory, and I/O modules (1.87-GB/sec sustained system bandwidth; 2.1-GB/sec peak bandwidth)
