What’s New
At A Glance
Standard Features
Available in multiple configurations.
Processor – One of the following
Intel Pentium III Xeon processor 550 MHz
Intel Pentium III Xeon processor 500 MHz
Cache Memory – One of the following
1-MB level 2 writeback cache per processor standard,
512-KB or 2-MB level 2 writeback cache per processor optional
512-KB level 2 writeback cache per processor standard,
1-MB or 2-MB level 2 writeback cache per processor optional
Upgradability
Upgradable to quad processing
| Memory | |
| Standard | 256 MB |
| Maximum | 4 GB |
Network Controller
Compaq NC3120 10/100 TX PCI UTP controller occupying one PCI slot
6/550 Model 1
6/550 Model 2
6/500 Model 1
6/500 Model 2
| Expansion Slots | |
| I/O (Total) | 7,5 available |
| PCI | 6 |
| Shared PCI/ISA | 1 |
Storage Controller
Compaq 64-bit Dual Channel Wide Ultra2 SCSI Adapter occupying one PCI
slot (operating at 32-Bit speeds)
(only in Wide Ultra2 models)
| Storage | |
| Diskette Drives | 1.44 MB |
| CD-ROM | 32X Max or faster IDE CD-ROM Drive |
| Hard Drives | None |
| Maximum Internal Storage | 182 GB (internal hot plug Wide Ultra2/Ultra3 drive cage only) (10 x 18.2) |
| Maximum Internal Storage | 218.4 GB (internal hot plug Wide-Ultra SCSI-3 drive cage only) (6 x 36.4) |
| Interfaces | |
| Parallel | 1 |
| Serial | 2 |
| Pointing Device (Mouse) | 1 |
| Graphics | 1 |
| Hot Plug Keyboard | 1 |
| External Wide-Ultra SCSI-3 | 1 |
| 64-Bit Wide Ultra2 SCSI Adapter | 1 (Only in Ultra2 models) |
| Network RJ-45 | 1 |
Graphics
Integrated 1280 x 1024, 256 color on PCI local bus, 2-MB video memory
Form Factor
Tower or optional 7U rack
| Compaq Software | |
| Compaq Insight Manager | The comprehensive system management tool that monitors the operation of Compaq servers, workstations and clients |
| Compaq SmartStart | The server configuration and software integration tool from Compaq |
| Array Configuration Utility (ACU) with Smart Array Controllers | Same easy to use yet powerful graphical user interface (GUI) configuration utility and easy to navigate wizards for all Smart Array Controllers |
Manageability
Automatic Server Recovery-2 (ASR-2)
Integrated Remote Console (IRC)
Hardware Remote Console
Full Remote Server Reboot Capability
Reset and Failure Sequence Replay
Host Hardware Independent
Operating System Independent
Server Health Logging
Revision History Table
Automatic Revision Tracking
Drive Parameter Tracking (with Smart Array Controller)
Dynamic Sector Repairing (with Smart Array Controller)
Off-Line Backup Processor capability
Pre-Failure Warranty (covers processors, hard drives and memory)
Redundant Fan Support
Security
Power-on password
Hot plug keyboard password
Diskette drive control
Diskette boot control
QuickLock, Network Server Mode
Parallel and serial interface control
Administrator's password
Disk configuration lock
Power supply security bar
Power Supply
750/500-Watt Hot Plug Power Supply
OS Support
Microsoft Windows NT
Microsoft Windows 2000 Server
Novell NetWare
SCO UnixWare and OpenServer
IBM OS/2 Warp Family
Sun Solaris Intel Platform Edition
Banyan VINES
Service and Support
Compaq Services provides a wide range of service offerings, including a
three-year, limited warranty fully supported by a worldwide network of
resellers and service providers, lifetime toll-free 7 x 24 hardware
technical phone support and Pre-Failure Warranty coverage of hard
drives, memory and processors. Disaster recovery services are available
through partnership with Comdisco.
