What’s New

• Intel Pentium^® III Xeon^TM 550-MHz Processor (quad processor capability)
• Improved hot plug redundant fan design provides 7x24 cooling across your entire system (Standard on 550-MHz Models, Optional on 500-MHz Models)

At A Glance

• Ideal combination of 4-way computing power and density that best fits space constrained data center environments
• Innovative, space saving 4U (7² ) rack-optimized design
• Supports one to four Intel Pentium III Xeon processors with 512-KB, 1-MB, or 2-MB L2 Cache
• ECC protected buffered EDO DIMM memory, (4 GB Maximum)
• Six 64-bit slots (five PCI Hot Plug and one shared PCI/ISA)
• NC3131 64-bit PCI dual port 10/100 Controller upgradable to
  1 Gigabit
• Internal Hot Plug Drive Storage of up to 72.8 GB with 18.2-GB 1? Wide Ultra2/Ultra3 hard drives
• Standard Wide Ultra2/Ultra3 Drive Cage
• Integrated Remote Console (IRC)
• Uncompromising reliability features:

Industry-Standard PCI Hot Plug with new push button functionality
Redundant hot plug fans
Optional redundant hot plug power supplies
Optional redundant power processor modules (standard on 2-MB models)
ASR-2 and Online Recovery Server Option

• Diagnostic interlocks for enhanced serviceability
• Toolless internal design for easy access to system components
• Protected by Compaq Services, including a limited three-year parts, labor and on-site warranty with optional four hour response. Pre-Failure Warranty and Compaq Service and Support Programs available on a Worldwide basis — Certain restrictions and exclusions apply. Consult the Compaq Customer Support Center at 1-800-345-1518 for details.

Standard Features

Processor – One of the following:
Intel Pentium III Xeon processor 550 MHz
Intel Pentium III Xeon processor 500 MHz

Cache Memory – One of the following:
2-MB level 2 writeback cache per processor standard
1-MB level 2 writeback cache per processor standard
512-KB level 2 writeback cache per processor standard

Upgradability
Upgradable to quad processing
Support for future processor upgrades

Network Controller
NC3131 64-bit PCI dual port 10/100 Controller

Storage Controller
Integrated Dual Channel Wide-Ultra SCSI-3 Adapter

Graphics
Integrated 1280 x 1024, 256 color on PCI local bus, 2-MB video memory

Form Factor
Rack (4U), ships with sliding rails and cable management

Manageability
Integrated Remote Console-IRC (with an internal modem)
Integrated Management Log (IML)
Server Health logging
Automatic Server Recovery-2 (ASR-2)
Recovery Server Option
Off-Line Backup Processor capability
PCI Hot Plug with push button functionality
Redundant Hot Plug Fans
(Full system fan redundancy is standard on 550-MHz Models. Achieve full system fan redundancy on your 500-MHz Models by installing the Compaq Hot Plug Redundant System Fan Option Kit [P/N 157984-B21].)
Dynamic sector repairing and drive parameter tracking (with Smart Array controllers)
Redundant Processor Power Modules (optional)
Redundant / adaptive load balancing NIC Support
Redundant Hot Plug Power Supplies (optional)
Pre-Failure Warranty (covers processors, as well as hard drives and memory)

Security
Power-on password
Hot plug keyboard password
Diskette drive control
Diskette boot control
Network Server Mode
Security Provision
Parallel and serial interface control
Administrator's password
Disk configuration lock
Hot plug access security

Power Supply
450-Watt Hot Plug Power Supply (optional Redundant Hot Plug Power Supply)

OS Support
Microsoft Windows NT
Microsoft Windows 2000 Server
Novell NetWare, IntraNetWare
SCO UnixWare and OpenServer
IBM OS/2 Warp Family
Sun Solaris Intel Platform Edition
Banyan Vines
Linux RedHat

Service and Support
Compaq Services provides a wide range of service offerings, including a three-year, limited warranty fully supported by a worldwide network of resellers and service providers, lifetime toll-free 7 x 24 hardware technical phone support and Pre-Failure Warranty coverage of hard drives, memory and processors. Disaster recovery services are available through partnership with Comdisco.
